Service Call 700-792
SM 5-103 D146/D147/D148/D149/D150
5.8 SERVICE CALL 700-792
5.8.1 SC700 (ENGINE: PERIPHERALS)
SC No. Level Error Name/Error Condition/Major Cause/Solution
SC700 1-pass ADF error
SC700-01 D Base Plate Lift Motor Error (1-pass ADF)
SC700-02 D Original Pick-up Error (1-pass ADF)
SC700-04 D Paper Feed Motor Error (1-pass ADF)
SC700-05 D Pullout Motor Error (1-pass ADF)
SC700-06 D Intermediate Motor Error (1-pass ADF)
SC700-07 D Scanning Motor Error (1-pass ADF)
SC700-09 D Paper Exit Motor Error (1-pass ADF)
-01
Even if the base plate motor is rotated in the base plate ascent
direction, the base plate paper feed correct position sensor does
not detect.
Even if the base plate motor is rotated in the base plate descent
direction, the base plate home position sensor does not detect.
-02
Even if the pick up arm motor is rotated, the pick up arm home
position sensor does not detect.
-04, 05, 06, 07, 09
When an error notification signal is detected during the motor
drive period.
To Next Page
