PM Parts Settings
SM 3-1 D146/D147/D148/D149/D150
Maintenance
3. PREVENTIVE MAINTENANCE
3.1 PM PARTS SETTINGS
3.1.1 REPLACEMENT PROCEDURE OF THE PM PARTS
1. Enter the SP mode.
2. Output the SMC logging data with SP5-990-004.
3. Set the following SPs to "1" before you turn the power off.
4. Replace the PM parts and turn the power on, then, the machine will reset the PM counters
automatically. In the case of developer, the developer initialization will also be done
automatically.
5. Exit the SP mode.
Item SP
PCDU
Black: 3701-002, 003
Yellow: 3701-025, 026
Cyan: 3701-048, 049
Magenta: 3701-071, 072
Development unit
Black: 3701-003
Yellow: 3701-026
Cyan: 3701-049
Magenta: 3701-072
PCU
Black: 3701-002
Yellow: 3701-025
Cyan: 3701-048
Magenta: 3701-071
Pressure Roller
(not necessary for complete fusing unit
and
Heating sleeve belt unit; see below)
Pressure roller: 3701-118
Image Transfer Belt Unit 3701-093
Image Transfer Belt Cleaning Unit 3701-102
PTR Unit 3701-109
To Next Page
