6.13.2 All G functions
All G groups and their group numbers are listed in the "G Functions" window.
Within a G group, only the G function currently active in the controller is displayed.
Additional information in the footer
The following additional information is displayed in the footer:
● Actual transformations
Display Meaning
TRANSMIT Polar transformation active
TRACYL Cylinder surface transformation active
TRAORI Orientation transformation active
TRAANG Inclined axis transformation active
TRACON Cascaded transformation active
For TRACON, two transformations (TRAANG and TRACYL or TRAANG and
TRANSMIT) are activated in succession.
● Current work offsets
● Spindle speed
● Path feedrate
● Active tool
6.13.3 G functions for mold making
In the window "G functions", important information for machining free-form surfaces can be
displayed using the "High Speed Settings" function (CYCLE832).
Software option
You require the "Advanced Surface" software option in order to use this function.
High-speed cutting information
In addition to the information that is provided in the "All G functions" window, the following
programmed values of the following specific information is also displayed:
● CTOL
● OTOL
● STOLF
The tolerances for G0 are only displayed if they are active.
Particularly important G groups are highlighted.
You have the option to configure which G functions are highlighted.
Machining the workpiece
6.13 Displaying G Functions and Auxiliary Functions
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 251
