13.4 Tool dimensioning
This section provides an overview of the dimensioning of tools.
Tool types
'LDPHWHU
/HQJWK
Figure 13-5 End mill (Type 120)
/HQJWK
'LDPHWHU
2XWHUGLDPHWHU
Figure 13-6 Face mill (Type 140)
Tool management
13.4 Tool dimensioning
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 691
