3. Clear spigot 1
4. Contour blank 2
5. Contour spigot 2
6. Clear spigot 2
7. Contour blank 1
8. Contour spigot 1
9. Clear residual material spigot 1
10.Contour blank 2
11.Contour spigot 2
12.Clear residual material spigot 2
Software option
For removing residual material, you require the option "residual material detec‐
tion and machining".
Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Contour milling" and "Spigot Res. Mat." softkeys.
The "Spigot Res. Mat." input window opens.
3. For the ShopMill program, press the "All parameters" softkey if you want
to enter additional parameters.
Parameters, G code program Parameters, ShopMill program
PRG Name of the program to be generated T Tool name
PL Machining plane F Feedrate mm/min
mm/tooth
Milling direction
● Synchronous
operation
● Up-cut
operation
S / V Spindle speed or constant cutting
rate
rpm
m/min
RP Retraction plane mm
SC Safety clearance mm
F Feedrate mm/min
Programming technological functions (cycles)
10.3 Contour milling
Milling
512 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
