Tektronix AFG31000 Series User Manual

Function introduction
AFG31000 Series Arbitrary Function Generator User's Manual 107
Advanced thumbnail
This is a small version of the waveform screen.
Figure 91: Thumbnail
Tutorial: Advanced mode
This example will show you how to use the AFG31000 Series Arbitrary Function Generator to
generate long waveforms or waveforms with complex timing. Generating pulse trains or data packets
in a serial bus are an example of this type of application.
Advanced mode provides 16MB per channel, with an optional expansion to 128MB, and supports 256
sequencing entries. You control the waveforms in the instrument by branching using repeat, wait,
jump, go to, or by triggering with events using external trigger in, manual trigger, timer, and SCPI
commands.
This application example shows how to compile a simple sequence with three entries, and how to
change how they are displayed on the instrument.
Equipment list
 One AFG31000 Series Arbitrary Function Generator
 One 4-channel Oscilloscope
 Three BNC to BNC cables
