Tektronix AFG31000 Series User Manual

Function introduction
AFG31000 Series Arbitrary Function Generator User's Manual 119
System menu settings
The System function screen contains the following settings:
 Language: Select from the following languages for your instrument: English, French,
German, Japanese, Korean, Simplified Chinese, Traditional Chinese, or Russian.
 Soft keyboard: Select On to enable the touchscreen keyboard when you need it. Select Off
if you do not want to use the touchscreen keyboard.
 Trigger Out: Select Sync or Trigger depending on your need (see Synchronous operation
(on page 78) and Trigger Out (on page 67) for more information).
 Clock Ref: Set the reference clock to Internal or External.
 Power On: Select Last or Default when you power on your instrument (see Change
instrument settings (on page 120) for more information).
 Screen Saver: Select On or Off. Choose On if you want the screen to become blank if there
is not any touchscreen activity for more than five minutes. If you want the screen to stay on
continuously, select Off.
 Click Tone: Select On or Off depending on your preference. If this option is on, you will hear
a tone when using the front panel buttons. If you select Off, you will not hear a tone.
 Beeper: Select On or Off. If this option is on, you will hear a beep when a message box
appears on your screen. If you select Off, you will not hear a beep.
 Factory Default: Resets the instrument to factory default settings.
 Brightness: Use the brightness slider to adjust the touchscreen brightness.
 ZONE: Set the required time zone.
Figure 112: System settings
