AFG31000 Series Arbitrary Function Generator User's Manual 27
Before installation
Inspect the instrument carton for external damage. If the carton is damaged, notify the carrier.
Remove the instrument from its package and make sure that it has not been damaged in transit.
Verify that the carton contains the instrument and its standard accessories.
Operating requirements
Place the instrument on a cart or bench, observing the following clearance requirements:
Sides: 50 mm (2 in)
Rear: 50 mm (2 in)
Before operating the instrument, make sure that the ambient temperature is between 0 °C to 50 °C.
Figure 1: AFG31000 Series two-channel front panel
CAUTION. To ensure proper cooling, keep both sides of the instrument clear of obstructions.
Section
Getting started
