42-16
2 - Cotter pin
Always replace
3 - Locking ring
4 - Hex nut
Adjusting wheel
bearing play Fig. 4
5 - Thrust washer
6 - Outer wheel bearing
Drive out outer race
with copper drift
Pressing in Fig. 6
7 - Hex socket head bolt,
10 Nm (7 ft lb)
8 - Speed sensor
Only on vehicles with
ABS
9 - Stub axle
Straightening
operations are not
permitted!
Page
2
of
18
Wheel bearings, servicing
12/7/2004
