46-45
Brake Light Switch, adjusting
Note:
The Brake Light Switch must be removed for
adjusting.
- Remove trim under instrument panel.
- Disconnect harness connector for Brake Light
Switch.
- Remove Brake Light Switch by turning to right
through 90.
- Pull Brake Light Switch plunger fully out.
- Depress brake pedal as far as possible by hand,
guide Brake Light Switch through the locating
hole and secure by turning through 90to left.
- Pull brake pedal back up by hand to stop (Brake
Light Switch is pushed back by one notch).
- Connect harness connector for Brake Light
Switch
- Check function of Brake Light Switch.
- Install instrument panel trim.
Parking brake lever assembly overview
