48-85
Assembly overview: vane pump,
reservoir and hydraulic lines (vehicles
with 4-Cyl. engines)
It is not intended that repair work be carried out
on the vane pump. If complaints are received
determine cause with the help of pressure and
leakage tests. Replace pump if faulty.
Note:
Pumps supplied as spare parts are not filled
with oil. Fill the pump with G 002 000 hydraulic
oil to rotate it by hand, otherwise the pump may
be damaged or noisy during operation.
Type of oil: hydraulic oil G 002 000
Oil system capacity: 0.7 - 0.9 Itr. (0.74 - 0.95
qt.)
Do not reuse drained hydraulic oil.
Always replace O-rings.
