40-16
6 - Speed sensor rotor
Only on vehicles with
ABS
7 - Hex bolt, 10 Nm (7 ft lb)
8 - Splash plate
9 - Circlip
Ensure correctly
seated
10 - Wheel bearing
Pressing out Fig. 6
Replace, as it is
destroyed during
pressing out
Pressing in Fig. 7
11 - Self-
locking hex nut, 35
Nm (26 ft lb)
12 - Wheel bearing housing
13 - Self-
locking hex nut, 50
Nm (37 ft lb)
14 - Hex bolt
Clamping bolt for ball
joint
Page
16
of
82
Front Wheel Suspension, Shafts and Axle
