46-44
Brake pedal, removing and installing
Note:
Grease all mounting and contact surfaces with
MoS
2
grease.
To remove brake servo disconnect brake pedal
at clevis only.
Removing
- Before removing brake pedal remove trim
- Remove brake pedal clevis pin connection
securing clip.
- Remove pin.
- Remove brake pedal pivot pin securing clip.
- Remove pivot pin.
- Remove mounting sleeve, return spring
mounting tube with brake pedal.
Installing
- Install in reverse order.
Page
8
of
9
Parking brake lever assembly overview
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.46.6
