42-37
Before installing, bring control arm into horizontal
position (unladen state). Removing and installing
suspension strut at body Page 42-4 .
Tightening torque -A-: 65 Nm (48 ft lb)
Note:
Support control arm otherwise damage may occur to
constant velocity joint as a result of over-stressing.
Fig. 1 Suspension strut from control arm,
removing and installing
Before removing propshaft, mark installation position.
If installed offset, imbalance will be excessive.
Tightening torque -A- and -B-: 45 Nm (33 ft lb)
Note:
Always support propshaft with wire otherwise
constant universal joint will be damaged.
Fig. 2 Driveshaft and drive axle, removing and
installing at differential
Rear axle, servicing (four wheel drive vehicles)
