42-50
11 - Circlip
Always replace
Insert in shaft groove
12 -
Outer constant velocity
joint: 81 mm diameter
Only replace complete
Removing Page 40-
54
Installing: drive onto
shaft with plastic
hammer until
compressed circlip
seats
Greasing Notes
Page 42-46
Checking Page 40-
60
13 - Inner support rings
Prevents boot inflating
Only installed on left
drive shaft
transmission end
Page
5
of
7
Rear drive shafts, servicing
12/7/2004
