44-2
Vehicle alignment specifications (front wheel drive vehicles)
Front axle
Suspension strut axle
Engine up to 85 kW (115
hp)
110 - 128 kW
(148 - 172 hp)
Version Base suspension Plus
suspension
Total toe
1)
(not pressed)
0 10' 0 10'
Camber
2)
(in straight- ahead position) Maximum permissible
difference between sides
-1 20' 20'
max. 20'
-1 10' 20'
max. 20'
Toe angle difference at 20left and right lock -1 10' 30' -1 40' 30'
Caster (not adjustable) Maximum permissible difference between
sides
+1 40' 30'
max. 30'
+3 20' 30'
max. 30'
1)
Only adjust total toe on right toe rod
2)
Camber corrections can only be made at the wheel bearing housing/suspension strut connection.
Camber adjustment Page 44-6 .
Note:
After adjusting steering geometry check position of steering wheel; correct if necessary.
