48-66
For easier installation of the puller, it is recommended
that a rubber band be placed around the jaws.
Illustration shows the housing in cross section for
better view.
Sealing ring for valve body, removing
1 - Puller e.g. Kukko 21/4
2 - Rubber band
3 - Sealing ring
4 - Housing
When installing the puller A, make sure that the claws
(arrows on fig. N48-0058, page 46) engage
correctly under the sealing ring. The puller must not
be spread too wide because otherwise the seat for
the sealing ring and the housing will be damaged or
the sealing ring can jam in the housing.
- Drive sealing ring out toward the top
A - Puller, e.g. Kukko 21/4
B - Driver
- Drive out lower ball bearing with VW 439
