REAR SHOCK ABSORBER ASSEMBLY
4-60
EAS23160
REAR SHOCK ABSORBER ASSEMBLY
Removing the rear shock absorber assembly
Order Job/Parts to remove Q’ty Remarks
Exhaust pipe assembly brackets Refer to “ENGINE REMOVAL” on page 5-1.
Rear wheel Refer to “REAR WHEEL” on page 4-11.
Fuel tank Refer to “FUEL TANK” on page 7-1.
1 Connecting arm nut/Washer/Bolt 2/2/2
2 Connecting arm 2
3
Rear shock absorber assembly lower nut/Wash-
er/Bolt
1/1/1
4 Rear shock absorber assembly bracket nut 1
5 Rear shock absorber assembly upper nut/Bolt 1/1
6 Rear shock absorber assembly bracket 1
7 Rear shock absorber assembly 1
8Spacer bolt 1
9 Relay arm nut/Bolt/Spacer 1/1/1
10 Relay arm 1
11 Spacer 1
12 Spacer 1
1
1
1
1
2
9
13
15
14
13
12
15
10
9
9
3
5
13
8
4
6
7
14
13
11
3
5
2
1
1
LS
LS
LS
LS
LS
New
New
New
New
13
3
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
52 Nm (5.2 m
•
kg, 37 ft
•
Ib)
T
R
.
.
44 Nm (4.4 m
•
kg, 32 ft
•
Ib)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
