CHARGING SYSTEM
8-15
EAS27230
TROUBLESHOOTING
The battery is not being charged.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Fuel tank
3. Bottom cowlings
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuse.
(Main)
Refer to “CHECKING THE FUS-
ES” on page 8-85.
Replace the fuse.
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-86.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the stator coil.
Refer to “CHECKING THE STATOR
COIL” on page 8-94.
• Replace the stator coil assembly.
4. Check the rectifier/regulator.
Refer to “CHECKING THE RECTI-
FIER/REGULATOR” on page 8-94.
Replace the rectifier/regulator.
5. Check the entire charging system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-13.
Properly connect or repair the charging
system’s wiring.
The charging system circuit is OK.
