SWINGARM
4-65
EAS23330
SWINGARM
Removing the swingarm
Order Job/Parts to remove Q’ty Remarks
Rear wheel Refer to “REAR WHEEL” on page 4-11.
Rear shock absorber
Refer to “REAR SHOCK ABSORBER AS-
SEMBLY” on page 4-60.
Drive chain guide (drive sprocket side) Refer to “CHAIN DRIVE” on page 4-70.
1 Drive chain adjusting locknut 2
2 Drive chain puller 2
3 Drive chain adjusting bolt 2
4 Rear fender 1
5 Drive chain guard 1
6 Drive chain guide (swingarm side) 1
7 Drive chain 1
8 Swingarm pivot shaft nut 1
9 Washer 1
10 Swingarm pivot shaft ring nut 1
11 Washer 1
12 Swingarm pivot shaft 1
4
16
9
14
14
20
13
15
19
17
6
5
3
10
12
8
3
2
18
11
1
1
2
LS
LS
20
19
7
LS
LS
New
New
LS
LS
LS
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
70 Nm (7.0 m
•
kg, 50 ft
•
lb)
T
R
.
.
95 Nm (9.5 m
•
kg, 68 ft
•
Ib)
