FUEL PUMP SYSTEM
8-75
EAS27570
TROUBLESHOOTING
If the fuel pump fails to operate.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Fuel tank
3. Side cowlings
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition and fuel injection
system)
Refer to “CHECKING THE FUS-
ES” on page 8-85.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-86.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-81.
Replace the main switch.
4. Check the engine stop switch.
Refer to “CHECKING THE
SWITCHES” on page 8-81.
Replace the right handlebar switch.
5. Check the relay unit (fuel pump re-
lay).
Refer to “CHECKING THE RE-
LAYS” on page 8-89.
Replace the relay unit.
6. Check the fuel pump.
Refer to “CHECKING THE FUEL
PUMP” on page 8-98.
Replace the fuel pump.
7. Check the entire fuel pump sys-
tem’s wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-73.
Properly connect or repair the fuel pump
system’s wiring.
Replace the ECU.
To Next Page
