CRANKCASE
5-55
EAS25540
CRANKCASE
Separating the crankcase
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-1.
Cylinder head Refer to “CYLINDER HEAD” on page 5-15.
Starter clutch
Refer to “GENERATOR AND STARTER
CLUTCH” on page 5-26.
Shift shaft Refer to “SHIFT SHAFT” on page 5-47.
Pickup rotor Refer to “PICKUP ROTOR” on page 5-30.
Oil pump drive chain guide Refer to “CLUTCH” on page 5-37.
Oil pump assembly Refer to “OIL PUMP” on page 5-50.
1 Timing chain 1
2 Dipstick 1
3 Neutral switch lead 1
4 Neutral switch 1
5 Ventilation chamber cover 1
6 Ventilation chamber cover gasket 1
7 Oil pipe 1
8 Oil baffle plate 1 1
11
4
3
2
11
6
10
1
8
9
7
5
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
LS
New
New
New
New
New
LS
LS
LS
LT
LT
LT
LT
(3)
LT
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
(4)
