AIR FILTER CASE
7-5
ET2C01003
AIR FILTER CASE
Removing the air filter case and secondary injectors
Order Job/Parts to remove Q’ty Remarks
Fuel tank Refer to “FUEL TANK” on page 7-1.
1 Atmospheric pressure sensor coupler 1 Disconnect.
2 Atmospheric pressure sensor 1
3 Crankcase breather hose 1 Disconnect.
4 Sub-wire harness 3 coupler 1 Disconnect.
5
Fuel hose (primary injector fuel rail to second-
ary injector fuel rail)
1 Disconnect.
6 Upper air filter case 1
7 Secondary injector holder 1
8 Cylinder-#1 secondary injector coupler 1 Disconnect.
9 Cylinder-#2 secondary injector coupler 1 Disconnect.
10 Cylinder-#3 secondary injector coupler 1 Disconnect.
11 Cylinder-#4 secondary injector coupler 1 Disconnect.
12 Sub-wire harness 3 1
13 Secondary injector fuel rail 1
14 Secondary injector 4
6
16
19
19
17
5
4
18
3
1
15
(5)
(3)
(3)
(9)
(4)
7
9
8
12
10
11
13
14
14
14
14
2
New
New
New
New
New
T
R
.
.
5 Nm (0.5 m
•
kg, 3.6 ft
•
Ib)
T
R
.
.
5 Nm (0.5 m
•
kg, 3.6 ft
•
Ib)
T
R
.
.
4 Nm (0.4 m
•
kg, 2.9 ft
•
Ib)
LT
T
R
.
.
2 Nm (0.2 m
•
kg, 1.4 ft
•
Ib)
T
R
.
.
1.5 Nm (0.15 m
•
kg, 1.08 ft
•
lb)
