SIGNALING SYSTEM
8-23
EAS27290
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or indicator light.
• The horn fails to sound.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Fuel tank
3. Side cowlings
4. Bottom cowlings
5. Rear cowling
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
Checking the signaling system
The horn fails to sound.
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main, ignition and signaling sys-
tem)
Refer to “CHECKING THE FUS-
ES” on page 8-85.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-86.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-81.
Replace the main switch.
4. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or repair the signaling
system’s wiring.
Check the condition of each of the sig-
naling system’s circuits. Refer to
“Checking the signaling system”.
1. Check the horn switch.
Refer to “CHECKING THE
SWITCHES” on page 8-81.
Replace the left handlebar switch.
2. Check the horn.
Refer to “CHECKING THE HORN”
on page 8-95.
Replace the horn.
To Next Page
