ELECTRIC STARTING SYSTEM
8-11
EAS27190
TROUBLESHOOTING
The starter motor fails to turn.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Fuel tank
3. Air filter case
4. Canister (for California only)
5. Side cowlings
6. Thermostat
NG →
OK ↓
NG →
OK ↓
OK →
NG ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Main and ignition)
Refer to “CHECKING THE FUS-
ES” on page 8-85.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-86.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the starter motor operation.
Refer to “CHECKING THE START-
ER MOTOR OPERATION” on page
8-93.
Starter motor is OK. Perform the electric
starting system troubleshooting, starting
with step 5.
4. Check the starter motor.
Refer to “CHECKING THE START-
ER MOTOR” on page 5-35.
Repair or replace the starter motor.
5. Check the relay unit (starting circuit
cut-off relay).
Refer to “CHECKING THE RE-
LAYS” on page 8-89.
Replace the relay unit.
6. Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-91.
Replace the relay unit.
7. Check the starter relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-89.
Replace the starter relay.
