WATER PUMP
6-10
EAS26540
CHECKING THE WATER PUMP
1. Check:
• Water pump assembly
Cracks/damage → Replace.
2. Check:
• Water pump inlet hose
• Water pump outlet hose
• Water pump breather hose
Cracks/damage/wear → Replace.
EAS26590
INSTALLING THE WATER PUMP
1. Install:
• Water pump assembly “1”
• O-ring “2”
NOTE:
• Align the slit “a” on the impeller shaft with the
projection “b” on the oil pump shaft.
• Lubricate the O-ring with a thin coat of lithium-
soap-based grease.
2. Fill:
• Cooling system
(with the specified amount of the recom-
mended coolant)
Refer to “CHANGING THE COOLANT” on
page 3-19.
3. Check:
• Cooling system
Leaks → Repair or replace the faulty part.
4. Measure:
• Radiator cap opening pressure
Below the specified pressure → Replace the
radiator cap.
Refer to “CHECKING THE RADIATOR” on
page 6-3.
New
To Next Page
