Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
134
Parameter lcd_logo.url <y0000000000xx>.cfg
Description
It configures the access URL of the custom logo file.
Note: It works only if “phone_setting.lcd_logo.mode” is set to 2 (Custom Logo). It is not applicable to
T54S/T52S/T48S/T48G/T46S/T46G/T29G IP phones.
Permitted
Values
URL within 511 characters
Default Blank
Web UI Features->General Information->Upload Logo
Parameter lcd_logo.delete <y0000000000xx>.cfg
Description
It deletes all custom logo files.
Note: It is not applicable to T54S/T52S/T48S/T48G/T46S/T46G/T29G IP phones.
Permitted
Values
http://localhost/all
Default Blank
Example: Setting a Custom Logo Display
The following example shows the configuration for uploading a custom logo picture “logo.dob”, and then setting it to
display on the phone idle screen. The logo picture is customized and placed on the provisioning server “192.168.10.25”.
Example
lcd_logo.url =http://192.168.10.25/logo.dob
phone_setting.lcd_logo.mode =2
After provisioning, the phone displays the custom logo screen and the idle screen alternately.
Call Display
By default, the IP phones present the contact information (including avatar and identity) when receiving an incoming
call, dialing an outgoing call or engaging in a call.
You can configure what contact information presents and how to display the contact information. If the contact exists
in the phone directory, the phone displays the saved contact name and number. If not, it will use Calling Line Iden-
tification Presentation (CLIP) or Connected Line Identification Presentation (COLP) to display the contact’s identity.
Topic
Call Display Configuration
