Phone Customization
167
Supported Programmable Keys
The following tables list programmable keys for each phone model.
Pro-
grammable
Key IDs
CP920
T19(P)
E2
T23P/T23G/T2-
1(P) E2
T29G/T27-
G
T52S/T42G/T42S/T41-
P/
T41S/T40P/T40G
T54S/T48G/T48S/T46G/T46-
S
1
SoftKey-
1
SoftKey-
1
SoftKey1 SoftKey1 SoftKey1 SoftKey1
2
SoftKey-
2
SoftKey-
2
SoftKey2 SoftKey2 SoftKey2 SoftKey2
3
SoftKey-
3
SoftKey-
3
SoftKey3 SoftKey3 SoftKey3 SoftKey3
4
SoftKey-
4
SoftKey-
4
SoftKey4 SoftKey4 SoftKey4 SoftKey4
5 Up Up Up Up Up Up
6 Down Down Down Down Down Down
7 / Left Left Left Left Left
8 / Right Right Right Right Right
9 OK OK OK OK OK OK
10 / / Cancel Cancel Cancel Cancel
11 / / / CONF / /
12 / / / HOLD / HOLD
13 MUTE MUTE / MUTE MUTE MUTE
14 / TRAN TRAN TRAN TRAN
17 / Redial Redial Redial Redial Redial
18 /
Mes-
sage
Message Message Message Message
Programmable Keys Configuration
For T23P/T23G/T21(P) E2 IP phones, Cancel key can be configured only when “features.keep_mute.enable” is set to 0
(Disabled).
For T54S/T52S/T48S/T48G/T46S/T46G/T42G/T42S/T41P/T41S/T40P/T40G/T29G/T27G/T19(P) E2/CP920 IP phones, Mute
key can be configured only when “features.keep_mute.enable” is set to 0 (Disabled).
The following table lists the parameters you can use to configure programmable keys.
Parameter programablekey.type_range.custom <y0000000000xx>.cfg
Description
It configures the list for available programmable key types when configuring programmable keys.
To assign function types, specify programmable key type IDs which start with or without a symbol ”+”.
For example, “+2,15,16,7,4” or “2,15,16,7,4” means only “N/A”, “Forward”, “Line”, “BLF”, “ReCall”, “Hold”
types are available when you configure programmable keys.
