YOKOGAWA GX20 User Manual

4-14
IM 04L51B01-01EN
Unit Type GX/GP Register
Number Data Type
Expandable I/O Unit 5
I/O channel
I/O data 330001 to 331000 32-bit signed integer
331001 to 332000 32-bit floating point
332001 to 332500 16-bit signed integer
Status information 332500 to 333000 16-bit signed integer
Unit 6
I/O channel
I/O data 335001 to 336000 32-bit signed integer
336001 to 337000 32-bit floating point
337001 to 337500 16-bit signed integer
Status information 337501 to 338000 16-bit signed integer
Client/Master device
Read
Hold Register
Unit Type GX/GP Register
Number Data Type
GX/GP main unit I/O channel I/O data 400001 to 401000 32-bit signed integer
401001 to 402000 32-bit floating point
402001 to 402500 16-bit signed integer
Status information 402501 to 403000 16-bit signed integer
I/O channel
(continuous area)
I/O data 404001 to 404200 32-bit signed integer
404201 to 404400 32-bit floating point
404401 to 404500 16-bit signed integer
Status information 404501 to 404600 16-bit signed integer
Communication
channel
Communication
data
405001 to 406000 32-bit signed integer
406001 to 407000 32-bit floating point
407001 to 407500 16-bit signed integer
Status information 407501 to 408000 16-bit signed integer
Internal switch 408001 to 408100 16-bit signed integer
GX/GP operation setting 409001 to 410000 16-bit signed integer
Expandable I/O Unit 1
I/O channel
I/O data 410001 to 411000 32-bit signed integer
411001 to 412000 32-bit floating point
412001 to 412500 16-bit signed integer
Status information 412501 to 413000 16-bit signed integer
Unit 2
I/O channel
I/O data 415001 to 416000 32-bit signed integer
416001 to 417000 32-bit floating point
417001 to 417500 16-bit signed integer
Status information 417501 to 418000 16-bit signed integer
Unit 3
I/O channel
I/O data 420001 to 421000 32-bit signed integer
421001 to 422000 32-bit floating point
422001 to 422500 16-bit signed integer
Status information 422501 to 423000 16-bit signed integer
Unit 4
I/O channel
I/O data 425001 to 426000 32-bit signed integer
426001 to 427000 32-bit floating point
427001 to 427500 16-bit signed integer
Status information 427501 to 428000 16-bit signed integer
Unit 5
I/O channel
I/O data 430001 to 431000 32-bit signed integer
431001 to 432000 32-bit floating point
432001 to 432500 16-bit signed integer
Status information 432501 to 433000 16-bit signed integer
Unit 6
I/O channel
I/O data 435001 to 436000 32-bit signed integer
436001 to 437000 32-bit floating point
437001 to 437500 16-bit signed integer
I/O data 437501 to 438000 16-bit signed integer
Channel
properties
Channel
information
Channel properties 440001 to 465000 16-bit signed integer
Client/Master device
ReadWrite
4.5 Modbus Function and Register Assignments
