Unit I/O Channel Data Hold Register Data Type
GX/GP main unit Lower bytes of the channel 0901 data 400901 32-bit signed integer
Higher bytes of the channel 0901 data 400902
| |
Lower bytes of the channel 0950 data 400999
Higher bytes of the channel 0950 data 401000
Expandable I/O 1 Lower bytes of the channel 1001 data 410001
Higher bytes of the channel 1001 data 410002
| |
Lower bytes of the channel 1050 data 410099
Higher bytes of the channel 1050 data 410100
Lower bytes of the channel 1101 data 410101
Higher bytes of the channel 1101 data 410102
| |
Lower bytes of the channel 1150 data 410199
Higher bytes of the channel 1150 data 410200
Lower bytes of the channel 1201 data 410201
Higher bytes of the channel 1201 data 410202
| |
Lower bytes of the channel 1250 data 410299
Higher bytes of the channel 1250 data 410300
Lower bytes of the channel 1301 data 410301
Higher bytes of the channel 1301 data 410302
| |
Lower bytes of the channel 1350 data 410399
Higher bytes of the channel 1350 data 410400
Lower bytes of the channel 1401 data 410401
Higher bytes of the channel 1401 data 410402
| |
Lower bytes of the channel 1450 data 410499
Higher bytes of the channel 1450 data 410500
Lower bytes of the channel 1501 data 410501
Higher bytes of the channel 1501 data 410502
| |
Lower bytes of the channel 1550 data 410599
Higher bytes of the channel 1550 data 410600
Expandable I/O 2 Lower bytes of the channel 2001 data 415001
Higher bytes of the channel 2001 data 415002
| |
Lower bytes of the channel 2050 data 415099
Higher bytes of the channel 2050 data 415100
Lower bytes of the channel 2101 data 415101
Higher bytes of the channel 2101 data 415102
| |
Lower bytes of the channel 2150 data 415199
Higher bytes of the channel 2150 data 415200
Lower bytes of the channel 2201 data 415201
Higher bytes of the channel 2201 data 415202
| |
Lower bytes of the channel 2250 data 415299
Higher bytes of the channel 2250 data 415300
Lower bytes of the channel 2301 data 415301
Higher bytes of the channel 2301 data 415302
| |
Lower bytes of the channel 2350 data 415399
Higher bytes of the channel 2350 data 415400
Lower bytes of the channel 2401 data 415401
Higher bytes of the channel 2401 data 415402
| |
Lower bytes of the channel 2450 data 415499
Higher bytes of the channel 2450 data 415500
Lower bytes of the channel 2501 data 415501
Higher bytes of the channel 2501 data 415502
| |
Lower bytes of the channel 2550 data 415599
Higher bytes of the channel 2550 data 415600
Continued on next page
4.5 Modbus Function and Register Assignments
