Multistage STwrench User Guide
140 (326) 9836 4134 01 Edition 2.9
Specify the end-fitting tool number required for the Multistage.
If the tool recognition function is used to select the Pset/Multistage
automatically, this is the end-fitting tool number which activates the
Multistage.
Maximum value: 100
If enabled, before starting the Pset execution, the wrench needs to scan the
specified barcode. See the Identifier chapter.
To use the tool recognition function to automatically select Pset/Multistage,
see the Setting the source for Pset/Multistage/Job selection chapter. When
this function is used, this flag does not have any effect.
NOTE: These options are applied to all the Psets in the Multistage, and override the settings of
the various Psets.
7.3 Running a Multistage
Once the Multistage has been created in the wrench map area in ToolsTalk BLM, it is automatically sent
to the STwrench.
To execute the Multistage, select Prog. Mode from the main menu of the STwrench:
Select the Multistage from the list of available Multistages and click on the OK button on the wrench
keyboard to start Multistage execution.
NOTE: If the source program is set for Bar code or TAG, instead of selecting the Multistage
manually with the wrench keyboard, the Multistage selection is performed automatically by
reading the associated Bar Code or inserting the end-fitting tool in the wrench.
