STwrench User Guide System overview
9836 4134 01 Edition 2.9 57 (326)
2.4.11 STwrench holder
The STwrench holder can be installed on a table or a wall in a horizontal or vertical position in order to
hold the STwrench in a fixed position.
Simply position the STwrench in the holder (push the wrench until hearing the “click”) as shown in the
following figure:
To install the holder, refer to the following figure (dimensions are in millimeters):
position can be
adjusted by
loosening the
mounting screws
