STwrench User Guide Scheduled Maintenance
9836 4134 01 Edition 2.9 303 (326)
20 Scheduled Maintenance
20.1 Yearly Calibration
The STwrench needs to be recalibrated every year. Calibration must be performed by trained people, with
the STwrench Calibration KIT P/N 8059 0920 95, which consists of the STwrench Calibrator Software,
Calibration smartHEAD and the Service RBU.
20.2 Wrench Cleaning
Keep the STwrench clean.
After use, remove any traces of oil, grease and dust from the wrench, especially from the display, the
keyboard, and the mini USB port.
When the USB cable is not connected to the wrench, insert the plug to protect the port from dust.
Always keep the IRDA port and, if installed, the barcode reader module, clean.
Avoid using harsh detergents when cleaning the wrench.
20.3 Shock Indicator
The shock indicator must be white in color.
