Atlas Copco STwrench User Manual

STwrench User Guide Pset
9836 4134 01 Edition 2.9 93 (326)
Maximum value: 30 sec
End cycle
time
Applied when torque goes below the cycle start and reaches the 3
rd
Percentage value
(see LED settings); the default value is 0.1 second.
Minimum value: 0.1 sec
Maximum value: 5 sec
Loosening
monitoring
If the Loosening limit it is set to a value different from 0, the STwrench continues to
search for unwanted loosening operations also after the end of the test, for the time
specified here (in seconds).
Minimum value: 0 sec
Maximum value: 60 sec
The wrench ends the tightening operation if the torque drops beneath the Cycle Start value for longer than
the Ratchet time or the End cycle time as shown in the following figure:
6.4 Batch Parameters
Batch count
Set to Pset if you want to execute the Pset more than once.
Batch size
If Batch count is enabled, specify how many times the Pset must be executed.
Maximum value: 99
Cycle start
3
rd
Percentage
Ratchet time
End cycle time
Time
