STwrench User Guide Working with the QATnode
9836 4134 01 Edition 2.9 281 (326)
18.4.1 Configuring the Inputs
There are 6 inputs available, which means 64 possible configurations; each of them can be used to select a
tightening program or an “Action”.
Select Input settings:
NOTE: If neither the Source Program nor the Sub Source Job is set to QATnode, all the inputs
(including the Tool locked) are ignored during the operation.
configurations
tightening programs
Inputs configuration to select
the tightening program
Enable to reserve an input for settings the
wrench in the Locked mode
To Next Page
