Real Time Traces STwrench User Guide
210 (326) 9836 4134 01 Edition 2.9
14 Real Time Traces
The Real Time Traces function provides a new window with the real-time tightening trace for each test
executed.
The STwrench must be connected to the ToolsTalk BLM via:
• USB cable.
• IRC-W, if the RBU installed in the STwrench includes the API interfaces. In this case the
function is opened by the API application software and not from ToolsTalk BLM. See the
Working with the API chapter for more information about how to enable the Real Time
Traces via IRC-W.
NOTE: This function must be enabled and configured in the STwrench settings. See the
STwrench Controller Setup chapter for more information.
Once the function is enabled, the following window is shown by ToolsTalk BLM each time a Pset is
executed:
Test result
Ongoing
test
Click to expand
the trace
Previous
traces
