6-31
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 6 Configuring WLANsWireless Device Access
Configuring WLANs
The WLAN QoS level defines a specific 802.11e user priority (UP) for over-the-air traffic. This UP is
used to derive the over-the-wire priorities for non-WMM traffic, and it also acts as the ceiling when
managing WMM traffic with various levels of priorities. The access point uses this QoS-profile-specific
UP in accordance with the values in Table 6-1 to derive the IP DSCP value that is visible on the wired
LAN.
You can assign a QoS profile to a WLAN using the controller GUI or CLI.
Using the GUI to Assign a QoS Profile to a WLAN
Using the controller GUI, follow these steps to assign a QoS profile to a WLAN.
Step 1 If you have not already done so, configure one or more QoS profiles using the instructions in the “Using
the GUI to Configure QoS Profiles” section on page 4-45.
Step 2 Click WLANs to open the WLANs page.
Step 3 Click the ID number of the WLAN to which you want to assign a QoS profile.
Step 4 When the WLANs > Edit page appears, click the QoS tab.
Step 5 From the Quality of Service (QoS) drop-down box, choose one of the following:
• Platinum (voice)
• Gold (video)
• Silver (best effort)
• Bronze (background)
Note Silver (best effort) is the default value.
Table 6-1 Access Point QoS Translation Values
AVVID Traffic Type AVVID IP DSCP QoS Profile AVVID 802.1p IEEE 802.11e UP
Network control 56 (CS7) Platinum 7 7
Inter-network control
(CAPWAP control,
802.11 management)
48 (CS6) Platinum 6 7
Voice 46 (EF) Platinum 5 6
Interactive video 34 (AF41) Gold 4 5
Streaming video 32 (CS4) Gold 4 5
Mission critical 26 (AF31) Gold 3 4
Call signaling 24 (CS3) Gold 3 4
Transactional 18 (AF21) Silver 2 3
Network management 16 (CS2) Silver 2 3
Bulk data 10 (AF11) Bronze 1 2
Best effort 0 (BE) Silver 0 0
Scavenger 8 (CS1) Bronze 0 1
