9-10

FLYWHEEL/IGNITION COIL HRX217HYA • HRX217HZA

3. SIDE PLATE

REMOVAL/INSTALLATION

Remove the flywheel (P. 9 - 7 ).

BOLT (6 x 14 mm) (2)

SIDE PLATE

STOP SWITCH CORD

(HYA type only)

INSTALLATION:

Connect to the wide

terminal of the engine

stop switch.

HYA type shown:
