7-5

HRX217HYA • HRX217HZA RECOIL STARTER

4. RECOIL STARTER INSPECTION

1. Remove the recoil starter (P. 7 -3 ).

2. Check the operation of the ratchets by pulling the starter rope

out several times.

3. Check the tabs on the cooling fan for damage.

5. RECOIL STARTER ROPE REPLACEMENT

1. Remove the recoil starter (P. 7 -3 ).

2. Pull the starter rope until the starter rope is pulled out fully.

RATCHETS

TABS

STARTER

ROPE
