9-2

FLYWHEEL/IGNITION COIL HRX217HYA • HRX217HZA

1. IGNITION COIL

REMOVAL/INSTALLATION

HYA TYPE

Remove the fan cover (page 7-4

After installation, adjust the ignition coil air gap (page 9-5

IGNITION COIL

SPARK PLUG CAP

STOP SWITCH CORD CONNECTOR

6 x 23 mm BOLT (2)
