SERVICE INFORMATION HRX217HYA • HRX217HZA
BATTERY HAS LOW VOLTAGE (less than 12.7 V) (HZA type only)
Repair or replace the wire.
Stop the engine and check the charge
coil air gap (0.3 ~ 0.5 mm) (P. 9 - 5
).
12.9 V or more
Less than 12.9 V
after charging
OK
NG
Charge the battery for 24 hours using
06320-VH7-UA1 charger. Allow to rest for
1 hour and retest.
Check battery connections (P. 11-6 ).
With the engine running, check the
charge coil output current (P. 9 -11
).
Start the engine and verify the speed is
2950 ~ 3100 rpm (P. 3 - 1 7
).
Replace the ignition/charge coil (P. 9 - 3).
Reset the air gap to 0.3 mm and
check the charge coil output.
More than 0.5 mm
Less than 0.23 A
OK
Inspect the charge wire (red).
Replace the fuse.
NG
With the engine running, remove and
check the 3 A fuse (P. 11 - 6
).
OK
Replace the battery.
