14-3

HRX217HYA • HRX217HZA OPERATION

MULCH MODE

When the Clip Director lever is placed in the MULCH position, the shutter completely closes off the discharge chute

and recycles the grass clippings through the blades. The blades then recut the clippings until they fall to the lawn as

valuable mulch.

CLIP DIRECTOR LEVER

SHUTTER

GRASS

CLIPPINGS

MULCHED CLIPPINGS
