HP MSR SERIES User Manual

261
2. Click Add to enter the Add Trap Target Host page, as shown in Figure 264.
Figure 264 Adding a target host of SNMP traps
3. Configure the SNMP traps, as shown in Table 127.
Table 127 Configuration items
Item Descri
p
tion
Destination IP Address
Set the destination IP address.
Select the IP address type: IPv4/domain name or IPv6, and then
type the corresponding IP address or domain name in the field
according to the IP address type.
Security Name
Set the security name, which can be an SNMPv1 community
name, an SNMPv2c community name, or an SNMPv3
username.
UDP Port
Set UDP port number.
IMPORTANT:
The default port number is 162, which is the SNMP-specified port
used for receiving traps on the NMS. Generally (such as using IMC
or MIB Browser as the NMS), you can use the default port number.
To change this parameter to another value, make sure the
configuration is the same with that on the NMS.
Security Model
Select the security model, the SNMP version.
IMPORTANT:
The security model must be the same as that running on the NMS.
Otherwise, the NMS cannot receive any trap.
