MIMAKI JV5 Series User Manual

Setting the Printing Method
3-20
Setting for White-laying Printing
When using SS21W-2 (SPC-0504W-2) white ink, you can print with other colors after printing with white ink. This
section describes the method of printing with white ink and other color inks.
1
Perform the operations in P.3-16 Steps 1 to 6.
2
Press to select [WhiteLayPrt.].
3
Press the key.
4
Press to select the printing method.
• Set value: OFF, ON (LEVEL 1 to 3)
5
Press the key.
6
Press the key several times to end the setting.
Set Value Overview
OFF White ink and other color inks are printed at the same time.
ON
(LEVEL1 to 3
*1
)
*1. With this machine, you cannot set the order of synthesis.
Color inks are printed on the white ink a while after the white ink has been printed.
• If a larger number is set for LEVEL1 to 3, the time between printing white ink and printing
color inks becomes longer.
• If a large number is set for LEVEL, the drying property of white ink improves, but printing
time becomes longer.
• This function can be set only when SS21W-2 ink (6 colors + white) has been filled.
• Printing time is at least two times longer than that of normal printing.
• When printing is performed under the following conditions, the printing speed decreases because the
number of nozzles to be used is limited.
Setting of Printing
Quality
Resolution Printing Width
DRAFT 540 x 1,080 dpi 1,541 mm or more
FINE
720 x 1,080 dpi
1,155 mm or more
720 x 1,440 dpi
1,440 x 1,440 dpi 1,155 mm or more (577 mm for Vd data)
[1]PRINT MODE
DRAFT QUA L I TY < e n t >
[1]PRINT MODE
Wh i t e L a y P r t . < e n t >
[1]PRINT MODE
SETUP :
OFF
[1]PRINT MODE
SETUP :
ON(LEVEL1)
[1]PRINT MODE
Wh i t e L a y P r t . < e n t >
