Other Settings
3-28
List of Settings
The underlined has been set as default.
Function Name
Overview
Set Value
PINCH ROLLER
Setting the pinch roller pressure and the pinch
roller numbers according to the medium to be
used.
See P.3-5.
MEDIA COMP. A medium-feeding rate is corrected. See P.3-8.
DROP. POS CORRECT
Setting used when the thickness of the medium,
head height, or ink type is changed.
See P.3-10.
HEATER
The heater temperature is set.
See P.3-12.
The standby time and OFF time of the heaters
are set.
PRINT MODE
Printing quality is set.
See P.3-16.
A scanning direction is set.
Logical seek is set.
White-laying printing is set.
INK LAYER The number of ink layers is set. Once
to nine times
DRYING TIME
Ink drying time for each scanning is set.
See P.3-21.
Ink drying time after printing has been complete
is set.
AUTO CUT
Whether a medium is automatically cut after
printing is set.
ON/OFF
PRE-FEED
Whether a medium is fed back and forth before
printing is set.
ON/OFF
COLOR PATTERN
It is set whether a color pattern is printed on the
right edge of a medium.
*1
*1. When ON is set, maximum printing width becomes 18mm narrower.
When cutting only with RasterLinkPro4SG or later, maximum cutting width also becomes 18mm narrower. If it affects the data
layout, set to OFF.
ON/OFF
REFRESH The refreshing level of the heads is set. 0 to 3
VACUUM The ability to adsorb a medium is set.
STORONG / STANDARD /
LittleWEAK / WEAK /OFF
FEED SPEED
The speed at which a medium is fed during
printing, etc. is set.
10 to 100
to 200%
PRIORITY
The prioritized setting (by the host or the panel) is
determined.
INDIVIDUALLY / ALL HOST
/
ALL PANEL
AUTO CLEANING
Automatic head cleaning conducted for each
printing operation is set.
See P.3-24.
PRINT. CLEANING
Automatic head cleaning conducted during
printing is set.
See P.3-26.
