MIMAKI JV5 Series User Manual

4-2
Setting the Pinch Rollers
Set the pinch roller pressure and the pinch roller numbers according to the medium to be used.
Recommended Setting for the Pinch Roller Pressure and Number of Pinch Rollers
The table below shows the recommended pinch roller pressure for cutting:
Quantity of Pinch Rollers
The following table shows the quantity of pinch rollers for each model.
Check the pinch rollers on your machine for quantity.
Settings Set Value Overview
ENDS
HIGH
Set the pressure for the pinch rollers at both ends of the medium according to the
medium to be used.
MIDDLE
LOW
INNER
HIGH
Set the pressure for the pinch rollers other than those at both ends of the medium
according to usage.
MIDDLE
LOW
OFF
No.
2 to 7
*1
*1. The number of pinch rollers varies according to the machine type.
Set the number of the leftmost pinch roller according to the size of the medium to be
used.
Set pressure Usage
ENDS: High
INNER: High
For standard operation
ENDS: High
INNER: Low
Use this combination of settings when you want the streaks made by the pinch rollers on the
medium to be unnoticeable.
• This setting may cause misalignment of the medium depending on the
medium type, feeding rate, or medium width.
Medium width Required pinch rollers
Less than 600 mm Both ends only
600 to 1,300 mm Both ends + 1 middle pinch roller
1,300 mm or more Both ends + 2 middle pinch rollers
• When you use the machine under conditions other than the above, the medium may slip out of place
during cutting.
• Adjust the pinch roller pressure according to the situation.
Model Quantity
CJV30-160 7 pieces
CJV30-130 6 pieces
CJV30-100 4 pieces
CJV30-60 3 pieces
