MIMAKI JV5 Series User Manual

6-19
When Nozzle Clogging Cannot Be Solved
6 6
Maintenance
DISCHARGE & WASH
Ink is discharged from the head, damper, and tube for them to be cleaned.
1
Press the key in LOCAL to select the
printing mode.
2
Select [HD. MAINTENANCE] of the maintenance menu.
(1) Press the key.
(2) Press to select [MAINTENANCE] and press the key.
(3) Press to select [HD. MAINTENANCE].
(4) Press the key.
3
Press to select [DISCHARGE & WASH].
4
Press the key.
5
Remove the ink cartridge.
• Ink remaining in the head or tube is discharged into the waste ink
tank.
• When ink has been discharged completely, the screen on the right
appears.
6
Mount a cleaning solution cartridge on the ink station.
• The cleaning solution starts to be absorbed.
• When the cleaning solution has been absorbed completely, the
screen on the right appears.
7
Remove the cleaning solution cartridge.
• The cleaning solution remaining in the head or tube is discharged
into the waste ink tank.
• When the cleaning solution has been discharged completely, the
screen on the right appears.
• To use this function, the dedicated cleaning solution ( P.6-2"About Cleaning Solution") is required. In
addition, before performing the work, check whether ink to be filled again remains or not.
• When the following messages are displayed, check the waste ink tank and perform the operations
described on P.6-38 "If a Waste Ink Tank Confirmation Message Appears" as necessary.
Con f i rm a was t e tank
Con t i nue< >Exchange
Con f i rm a wa s t e tan k
Exchange :
e nt
<LOCAL . 1> [ #01 ]
WIDTH:****mm
MA I NT ENANCE
DISCHARGE&WASH <ent>
Remove : I n kCa r t r i dge
MMCCYYKK
*DISCHARGE*
00 : 00
Set:WashingCartr idge
12345678
*ABSORPTION*
00 : 00
Remove : Ca r t r i dges
12345678
*DISCHARGE*
00 : 00
Set:WashingCartr idge
12345678
