Related Manuals
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
NX-series EtherCAT®
Coupler Unit User’s Man-
ual
W519 NX-ECC Learning how to use an NX-
series EtherCAT Coupler
Unit and EtherCAT Slave
Terminals
The system and configuration of EtherCAT Slave
Terminals, which consist of an NX-series EtherCAT
Coupler Unit and NX Units, are described along
with the hardware, setup, and functions of the Eth-
erCAT Coupler Unit that are required to configure,
control, and monitor NX Units through EtherCAT.
NX-series Data
Reference Manual
W525
NX-  Referencing lists of the data
that is required to configure
systems with NX-series
Units.
Lists of the power consumptions, weights, and
other NX Unit data that is required to configure
systems with NX-series Units are provided.
NX-series NX Units
User’s Manuals
W521
NX-ID 
NX-IA 
NX-OC 
NX-OD 
NX-MD 
Learning how to use NX
Units
Describes the hardware, setup methods, and func-
tions of the NX Units.
Manuals are available for the following Units.
Digital I/O Units, Analog I/O Units, System Units,
Position Interface Units, Communications Interface
Units, Load Cell Input Units, and IO-Link Master
Units.
W522
NX-AD 
NX-DA 
W566 NX-TS
NX-HB
W523
NX-PD1 
NX-PF0 
NX-PC0 
NX-TBX01
W524 NX-EC0 
NX-ECS 
NX-PG0 
W540 NX-CIF
W565 NX-RS
W567 NX-ILM
GX-series EtherCAT
Slave Units User’s Man-
ual
W488 GX-ID
GX-OD
GX-OC
GX-MD
GX-AD
GX-DA
GX-EC
XWT-ID
XWT-OD
Learning how to use the
EtherCAT remote I/O
terminals.
Describes the hardware, setup methods and func-
tions of the EtherCAT remote I/O terminals.
AC Servomotors/Servo
Drives 1S-series with
Built-in EtherCAT® Com-
munications User’s Man-
ual
I586 R88M-1
R88D-1SN-
ECT
Learning how to use the
Servomotors/Servo Drives
with built-in EtherCAT Com-
munications.
Describes the hardware, setup methods and func-
tions of the Servomotors/Servo Drives with built-in
EtherCAT Communications.
AC Servomotors/Servo
Drives G5-series with
Built-in EtherCAT® Com-
munications User’s Man-
ual
I573 R88M-K
R88D-KN  -ECT-
R
Learning how to use the AC
Servomotors/Servo Drives
with built-in EtherCAT Com-
munications.
Describes the hardware, setup methods and func-
tions of the AC Servomotors/Servo Drives with
built-in EtherCAT Communications.
The linear motor type model and the model dedi-
cated for position controls are available in
G5-series.
I576 R88M-K
R88D-KN-ECT
I577 R88L-EC-
R88D-KN  -ECT-L
Manual name Cat. No. Model numbers Application Description
