3-25
3 Configuring Axes and Axes Groups
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
3-4 Setting Procedures for Axes Groups
3
3-4-1 Setting Procedure for an Axes Group
3-4 Setting Procedures for Axes Groups
This section gives the procedures to use the Sysmac Studio to set up an axes group. No configuration
is required if you are not going to use any axes group command instructions, such as linear interpola-
tion or circular interpolation.
This section gives the procedures to use the Sysmac Studio to set up an axes group in a project that
already contains the axes.
1 Start the Sysmac Studio and open the project.
3-4-1 Setting Procedure for an Axes Group
3-4-2 Setting Procedure
Starting the Sysmac Studio
START
END
Start the Sysmac Studio.
Add an axes group.
Set the axes group parameters.
Go online and synchronize the data.
Transfer the project to the Controller.
