1-7
1 Introduction to the Motion Control Function Module
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
1-4 Specifications
1
1-4-1 General Specifications
1-4 Specifications
This section gives the specifications of the MC Function Module.
Precautions for Correct UsePrecautions for Correct Use
The NX102-90 Units and NJ101-90 Units do not provide the Motion Control Function
Module.
General specifications conform to the general specifications of the CPU Unit.
Refer to the NX-series CPU Unit Hardware User’s Manual (Cat. No. W535) or NJ-series CPU Unit
Hardware User’s Manual (Cat. No. W500) for details.
The following table describes the performance specifications for each type of CPU Units.
*1 This is the total for all axis types. Refer to Axis Types on page 5-9 for details on axis types.
*2 This means the axes for which all motion control functions can be used.
*3 This means the axes for which only single-axis position control can be used among motion control functions. Refer to
Control Function on page 5-10 for details on a single-axis position control axis.
*4 This is the total number of axes whose axis type is set to Servo Axis or Encoder Axis and axis use is set to Used Axis.
1-4-1 General Specifications
1-4-2 Performance Specifications
Item
NX701-
17 16
Number of
controlled
axes
Maximum number of controlled axes
*1
256 axes 128 axes
Motion control axes
*2
256 axes 128 axes
Single-axis position con-
trol axes
*3
---
Maximum number of used real axes
*4
256 axes 128 axes
Used motion control servo
axes
256 axes 128 axes
Used single-axis position
control servo axes
---
Maximum number of axes for linear
interpolation axis control
4 axes per axes group
Number of axes for circular interpolation
axis control
2 axes per axes group
Maximum number of axes groups 64 axes groups
Override factors 0.00% or 0.01% to 500.00%
Motion control period The same control period as that is used for the process data
communications cycle for EtherCAT.
Multi-motion Supported.
Cams Number of
cam data
points
Maximum points per cam
table
65,535 points
Maximum points for all
cam tables
1,048,560 points
Maximum number of cam tables 640 tables
